BRICK STACK GRAPPLE KM 331 - 1000

Material number: 9854461
Product line: Accessories

Product images shown are for illustration purpose only. The actual product may vary.

Description

Hiab accessories are designed to help you to perform your daily job faster and easier.

Attributes

Height (mm): 1,455
Item Attachment Dimension: o 4 x 140 MM
Max Load (kg): 2,000
Opening Max: 220 - 1420
Plunge Depth: 1,000
Weight (kg): 255
Width (mm): 500

Downloads

KM 331 ME_MD_1.pdf

Model specifications

Brick grabs	KM331-1000	KM331 - 1100	KM331 - 1200	KM331 - 1300
Item Part No	9854461	9854479	9854487	9854495
Height (mm)	1,455	1,555	1,655	1,755
Item Attachment Dimension	o 4 x 140 MM	o 4 x 140 MM	o 4 x 140 MM	o 4 x 140 MM
Max Load (kg)	2,000	2,000	1,800	1,600
Opening Max	220 - 1420	160 - 1450	100 - 1475	40 - 1500
Plunge Depth	1,000	1,100	1,200	1,300
Weight (kg)	255	260	265	270
Width (mm)	500	500	500	500
Detail	Current variant	Variant detail	Variant detail	Variant detail
